AIR DRIVEN TORQUE WRENCH PUMP
유압펌프
SAB Series
AIR DRIVEN TORQUE WRENCH PUMP
Working pressure :
700 bar
High flow pump unit :
3-stage (speed)
- Air to prevent freezing and cools the oil
- Supplide fitted with one set of couplers
- Remote hand pendant controller with 5metres cable for easy operation
- Multi-outlet 4-way split block for simultaneous operation of up to 4 torque wrenchs
|
Model
number |
Power supply |
Pressure
gauge |
Gauge
reading |
Oil capacity (litres) |
Motor power (KW) |
Net weight
(Kg) |
|
SAB-700A
|
7 bar air |
analogue
|
bar/Mpa
|
5 | 1.1 |
22
|
|
Stage
|
Flow rate (l/m) |
Pressure
(bar) |
|
1
|
7 |
0~70
|
|
2
|
1.4 |
70~300
|
|
3
|
0.65 |
300~700
|
|
Dimensions
(mm) |
|
490 x 305 x 495
|
